POWER SUPPLY CP-E24/0.75
Article number: Suppl. article no:
5218700
1SVR427030R0000
to see price and stock
- Article number: 5218700
- Suppl. article no: 1SVR427030R0000
- Ean no: 4016779656863
- Material class QQ2200
Technical data
- 1st secondary output voltage: 24 V
- Nominal value output current 1: 0.75 A
- Max. output current 1: 0.8 A
- Secondary voltage adjustable: No
- Power output: 18 W
- Stabilized: Yes
- Rated supply voltage AC 50 Hz: 90-264 V
- Power consumption: 22.8 VA
- Rated supply voltage DC: 120-375 V
- Width: 22.5 mm
- Suitable for safety functions: No
- Short-circuit-proof: Yes
- Suitable for distribution board: No
- Performance level according to EN ISO 13849-1: None
- Degree of protection (IP): IP20
- Type of electric connection: Screw connection
- Max. output current 2: 0 A
- Max. output current 3: 0 A
- 2nd secondary output voltage: 0 V
- 3rd secondary output voltage: 0 V
- Voltage type (supply voltage): AC/DC
- Height: 90 mm
- Depth: 114 mm
- Direct mounting possible: No
- Built-in height: 90 mm
- Rated supply voltage AC 60 Hz: 90-264 V
- SIL according to IEC 61508: None
- Suitable for rail mounting: Yes
- Built-in width: 22.5 mm
- Nominal value output voltage 1: 24 V
- Nominal value output voltage 2: 0 V
- Nominal value output voltage 3: 0 V
- Nominal value output current 2: 0 A
- Nominal value output current 3: 0 A
- Degree of protection (NEMA): 1
- Output voltage stabilized: Yes
- Suitable for wall mounting: No
- REACH Date: 2023-01-18
- REACH Information obligation: No
