Eurolan
Floor cabinet 19" with metal door 60F, Eurolan
CABINET 42U 600X600 MET 60F-42-66-09GY
Article number: Suppl. article no:
2599284
60F-42-66-09GY
to see price and stock
Floor cabinet intended for active and passive network equipment in broadband or office networks. Eurolan Floor cabinet is intended for active and passive network equipment in broadband or office networks. Grounding kit and leveling legs included. Front door: Tinted glass with metal frame or all metal, both with locking function. The movable door can be opened both to the left and right and can be easily changed depending on which direction you prefer. Rear door: Metal, with locking function. Upper cover plate: Ventilation holes in the roof of the shed. Fan module can be mounted on the inside of the roof. Bottom: The cabinet can be placed directly on the floor, on the supplied level feet or on wheels (not included). 19" tracks: Zinc-coated steel tracks, adjustable in depth. Cable entries: A width-adjustable entry with thick rubber edges at the bottom and the possibility of cable entry in three places in the ceiling. They are fitted with plastic trays that can be removed if necessary.
- Article number: 2599284
- Suppl. article no: 60F-42-66-09GY
- Material class QM630B
Technical data
- Type: 60F-42-66-09GY
- Mounting level: Front and rear
- Type of profile rail: L-shape
- Number of height units: 42
- With glazed door: No
- Width: 800 mm
- Material front door: Steel
- Depth: 600 mm
- Material rear door: Steel
- Colour: Grey
- With front door: Yes
- Height: 2053 mm
- Number of doors: 1
- Material: Steel
- Demountable: No
- With rear door: Yes
- With earthing: No
- With sidewall: Yes
- With base: No
- With roof plate: Yes
- Model: With permanent frame
- Modular spacing: 482.6 mm (19 inch)
- RAL-number: 7035
- Degree of protection (IP): IP20
- Type of ventilation: Passive
- Surface finishing: Powder coating
- Rear door locking system: 1-point
- Front door locking system: 1-point
- Max. load capacity: 600 kg
- REACH Date: 2023-01-30
- REACH Information obligation: No
