Garo
Automatic fuse GR 3-pole type C 6kA
MCB GR C332 6kA MCB MCB GR C332
Article number: Suppl. article no:
2142289
2142289
to see price and stock
If the miniature circuit breakers belong to the 6kA program, they are suitable for residential housing installations, with C features w here C is more slow, which is suitable for microwave ovens,
motors, washing machines and tumble dryers. The product has also been tested and certified by SEMKO and is thereby S-marked. The product has a DIN rail attachment which allows
dismantling from the phase-rail without loosening the entire rail.
motors, washing machines and tumble dryers. The product has also been tested and certified by SEMKO and is thereby S-marked. The product has a DIN rail attachment which allows
dismantling from the phase-rail without loosening the entire rail.
- Article number: 2142289
- Suppl. article no: 2142289
- Ean no: 7331185114927
- Material class QL4000
Technical data
- Packagin Size: 1 ST/4 ST
- Type: MCB GR C332
- Rated current: 32 A
- Number of poles (total): 3
- Width in number of modular spacings: 3
- Release characteristic: C
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 6 kA
- Rated voltage: 230 V
- Degree of protection (IP): IP20
- REACH Date: 2021-06-15
- REACH Information obligation: No
