ABB
Miniature circuit breaker 1-pole. 6 kA S201 K
MINIATURE BREAKER S201 K2 S201-K2
Article number: Suppl. article no:
2100691
2CDS251001R0277
to see price and stock
K-automatics are suitable for protection of devices with high input currents, such as motors and compressors. Width 1 module 17.5 mm
- Article number: 2100691
- Suppl. article no: 2CDS251001R0277
- Ean no: 4016779507226
- Material class QL3300
Technical data
- Packagin Size: 1 ST/10 ST
- Type: S 201-K 2
- Rated current: 2 A
- Number of poles (total): 1
- Width in number of modular spacings: 1
- Release characteristic: K
- Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: 6 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: 10 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: 10 kA
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 6 kA
- Rated voltage: 230 V
- Voltage type: AC/DC
- Number of protected poles: 1
- Degree of protection (IP): IP20
- Frequency: 50-60 Hz
- Concurrently switching neutral conductor: No
- Current limiting class: 3
- Additional equipment possible: Yes
- Overvoltage category: 3
- Pollution degree: 3
- Connectable conductor cross section solid-core: 0.75-35 mm²
- Connectable conductor cross section multi-wired: 0.75-25 mm²
- Rated impulse withstand voltage Uimp: 4 kV
- Rated insulation voltage Ui: 440 V
- Ambient temperature during operating: -25-55 °C
- Explosion-proof: No
- Flush-mounted installation: No
- Built-in depth: 69 mm
- REACH Date: 2022-08-11
- REACH contains candidate substances: Bly
- GWP-tot (A1-A3): 0,7991 kgCO2e/ST
- REACH Information obligation: Yes
