ABB
Miniature circuit breaker, 3-pole. 6 kA S203 B
MINIATURE CIRCUIT BREAKER S203 B6 3-POLE 6KA
Article number: Suppl. article no:
2100440
2CDS253001R0065
to see price and stock
Width 3 modules 52.5 mm
- Article number: 2100440
- Suppl. article no: 2CDS253001R0065
- Ean no: 4016779468602
- Material class QL3300
Technical data
- Packagin Size: 1 ST/3 ST
- Type: S 203-B 6
- Rated current: 6 A
- Number of poles (total): 3
- Width in number of modular spacings: 3
- Release characteristic: B
- Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: 6 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: 20 kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: 10 kA
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 6 kA
- Rated voltage: 400 V
- Voltage type: AC/DC
- Number of protected poles: 3
- Degree of protection (IP): IP20
- Frequency: 50-60 Hz
- Concurrently switching neutral conductor: No
- Current limiting class: 3
- Additional equipment possible: Yes
- Overvoltage category: 3
- Pollution degree: 3
- Connectable conductor cross section solid-core: 0.75-35 mm²
- Connectable conductor cross section multi-wired: 0.75-25 mm²
- Rated impulse withstand voltage Uimp: 4 kV
- Rated insulation voltage Ui: 440 V
- Ambient temperature during operating: -25-55 °C
- Explosion-proof: No
- Flush-mounted installation: No
- Built-in depth: 69 mm
- REACH Date: 2022-08-11
- REACH contains candidate substances: Bly
- REACH Information obligation: Yes
