Kabeldon
Electric switch SEKOD 125
SWITCH-FUSE SEKOD 125
Article number: Suppl. article no:
0732793
6305.0233.0
to see price and stock
Fuse switch that breaks on both sides of the fuse. Fits the ABB Kabeldon IP system.
Protected during fuse replacement in accordance with protection class IP2X. Lockable handle in OFF position. Can be sealed. 3-pole breaking.
Protected during fuse replacement in accordance with protection class IP2X. Lockable handle in OFF position. Can be sealed. 3-pole breaking.
- Article number: 0732793
- Suppl. article no: 6305.0233.0
- Ean no: 7331980051465
- Material class QB6900
Technical data
- Max. rated operation voltage Ue AC: 690 V
- Number of poles: 3
- Conditioned rated short-circuit current Iq: 20 kA
- Type of control element: Long rotary handle
- Degree of protection (IP), front side: IP2X
- Position control element: Front side
- Version as safety switch: Yes
- Suitable for fuses: NH00
- Suitable for busbar mounting: Yes
- Motor drive optional: No
- Type of electrical connection of main circuit: Screw connection
- Motor drive integrated: No
- With error protection: No
- Rated short-time withstand current lcw: 5 kA
- Version as main switch: Yes
- Version as emergency stop installation: No
- Equipped with connectors: Yes
- Rated current: 125 A
- REACH Date: 2025-10-23
- Type: SEKOD 125
- REACH Information obligation: No
- Fuse size: 00
