Eurolan
Microduct 16/12 41P DB
DUCT DB 3X16/12+7X7/3.5 41P-03-39P-07GR
Article number: Suppl. article no:
5045061
41P-03-39P-07GR
to see price and stock
5045059 = Eurolan outdoor ducts for blown fiber installations in dimension 16/12. The three tubes are marked with orange/yellow and red stripe. Orange outer jacket.
5045061 = Eurolan outdoor ducts for blown fiber installations in dimension 3X16/12+7x7/3.5. With track wire. Green outer coat.
5045061 = Eurolan outdoor ducts for blown fiber installations in dimension 3X16/12+7x7/3.5. With track wire. Green outer coat.
- Article number: 5045061
- Suppl. article no: 41P-03-39P-07GR
- Ean no: 7333089012262
- Material class QR5380
Technical data
- Packagin Size: 2000 M
- Type: 41P-03-39P-07GR
- Outer diameter: 7 mm
- Inner diameter: 3.5 mm
- Number of glass fibre ducts: 10
- Bundle diameter: 34-39.3 mm
- Colour outer sheath: Green
- Suitable for: Outside
- Flame resistant: No
- Halogen free: No
- Armouring/reinforcement: None
- Metal-free: No
- Transparent: No
- Separable: Yes
- Watertight: Yes
- Suitable for outdoor installation: Yes
- Suitable for underground installation: Yes
- REACH Date: 2024-10-18
- REACH Information obligation: No
