Timer, electronic
TIMER ADJUSTABLE 2P ANT EXXACT
Article number: Suppl. article no:
1821361
WDE003471
to see price and stock
Exxact Electronic timer. Adjustable between 15 and 30 minutes plus 1, 2, 4 and 8 hours. Requires neutral conductor. For recessed mounting on the apparatus box c/c, 60 mm. For surface mounting box 35mm is used. Supplemented by optional Exxact frame. White
- Article number: 1821361
- Suppl. article no: WDE003471
- Ean no: 3606480204791
- Material class QH2500
Technical data
- Packagin Size: 1 ST/10 ST/1440 ST
- Type: WDE003471
- Product series: Exxact
- Model: Electronic
- Colour: Anthracite
- Timer function: No
- Time setting: 15-480 min
- Mounting method: Flush-mounted
- Max. power: 2300 W
- Nominal voltage: 230 V
- Rated current: 10 A
- Number of contacts as normally open contact: 2
- Type of fastening: Mounting with screw
- Surface finishing: Glossy
- Surface protection: Untreated
- Device width: 71 mm
- Device height: 71 mm
- Frequency: 50 Hz
- RAL-number (similar): 0
- Min. depth of built-in installation box: 24 mm
- Material: Plastic
- Shortest switching interval: 15 min
- Material quality: Thermoplastic
- Assembly arrangement: Basic element with central cover plate
- Substation input: No
- Astro program: No
- With brightness sensor connection: No
- Random generator: No
- Transparent: No
- Autonomy: 0 h
- Wi-Fi-compatible: No
- Operation by Bluetooth: No
- IFTTT support available: No
- Built-in depth: 32 mm
- Compatible with Amazon Alexa: No
- Compatible with Apple HomeKit: No
- Compatible with Google Assistant: No
- Suitable for degree of protection (IP): IP20
- REACH Date: 2025-07-18
- REACH contains candidate substances: Boroxid, Diboron trioxide | Lead oxide, Blyoxid, Blymonoxid, C.I. Pigment Yellow 46 , C.I. 77577, Litharge, Lead(II) oxide
- REACH Information obligation: Yes
