Schneider Electric
Wall-mounted cabinet with single door, IP66, Schneider
CABINET 600X500X250 NSYS3D6525P
Article number: Suppl. article no:
2578288
NSYS3D6525P
to see price and stock
The door is reversible left or right hand hinged. 3 locking points from height of 600 mm Including galvanized mounting plate, europa flange and cover plate. Cabinet with single door, IP66.
- Article number: 2578288
- Suppl. article no: NSYS3D6525P
- Ean no: 3606480159268
- Material class QM501B
Technical data
- Packagin Size: 1 PCS/18 PCS
- Type: NSYS3D6525P
- Design: 2B2 (E)
- Height: 600 mm
- Width: 500 mm
- Depth: 250 mm
- Number of doors: 1
- Material quality: Other
- With mounting plate: Yes
- Mounting plate depth-adjustable: No
- Number of locks: 1
- Material: Steel
- Surface finishing: Powder coating
- Colour: Grey
- RAL-number: 7035
- Connectable: No
- Degree of protection (IP): IP66
- Degree of protection (NEMA): 4X
- Impact strength: IK10
- Suitable for metrical mounting: Yes
- Suitable for outdoor set-up: Yes
- EMC-version: No
- Suitable for wall built-in: No
- With glazed door: No
- With ventilation door: No
- With rear door: No
- Pitched roof: No
- Pole fastening: Yes
- Number of connector holes: 0
- Freestanding: No
- Floor standing wall model: No
- Corner model: No
- Couplable: No
- Suitable for wall mounting: Yes
- Max. permitted load of the door(s) according to IEC 62208: 50 N
- Max. permitted load of the enclosure according to IEC 62208: 250 N
- Max. permitted load of the mounting plate according to IEC 62208: 250 N
- Intermediate mounting: No
- Pre-stamping: No
- With door: Yes
- With cover: No
- Transparent cover: No
- REACH Date: 2025-07-18
- GWP-tot (A1-A3): 83,0041 kgCO2e/ST
- REACH Information obligation: No
- Suitable for outdoor installation: No
