Connection cable PVC SKK-U round 300/300 V, Nexans
SKK 2X0.75 WHITE H03VV-F B100 B100
Article number: Suppl. article no:
0504703
22510512441
to see price and stock
The cable is intended for indoor use, for connecting lightweight portable devices, eg, table lamps and radios.
SKK (H03VV-F) is a round and light, lead-free, PVC-insulated, PVC-sheathed connecting cable with round, multi-stranded copper wire. The cable is designed in accordance with SS 424 02 31-5. The cables have a resistance in accordance with IEC 60228 class 5. The parts cabled together are colour marked according to SS 424 17 20. The sheath is marked "NEXANS GS SEMKO HAR year+mon". SKK-U meets fire requirements in accordance with IEC 60322-1 (F2). The cable has been approved by SEMKO.
Construction norm: SS 424 02 31-5. Fire class F 2.
SKK (H03VV-F) is a round and light, lead-free, PVC-insulated, PVC-sheathed connecting cable with round, multi-stranded copper wire. The cable is designed in accordance with SS 424 02 31-5. The cables have a resistance in accordance with IEC 60228 class 5. The parts cabled together are colour marked according to SS 424 17 20. The sheath is marked "NEXANS GS SEMKO HAR year+mon". SKK-U meets fire requirements in accordance with IEC 60322-1 (F2). The cable has been approved by SEMKO.
Construction norm: SS 424 02 31-5. Fire class F 2.
- Article number: 0504703
- Suppl. article no: 22510512441
- Ean no: 7330000020429
- Material class QA935A
Technical data
- Packagin Size: 100 M
- Cable type: SKK
- Dimension conductor x area: 2x0,75 mm²
- Reaction-to-fire according to EN 13501-6: Class: None
- Outer diameter approximate: 6.3 mm
- Nominal voltage U0: 300 V
- Nominal voltage U: 300 V
- With protective conductor: No
- Colour outer sheath: White
- Conductor category: Class 5 = flexible
- Conductor material: Copper
- Max. permitted conductor temperature: 70 °C
- Reaction-to-fire according to EN 13501-6: Acidity: None
- Material core insulation: Polyvinyl chloride (PVC)
- Conductor resistance at 20 °C: 26 Ohm/km
- Core identification: Colour
- Core identification according to HD 308 S2: Yes
- Shape of conductor: Round
- Nominal cross section conductor: 0.75 mm²
- Conductor surface: Bare
- Number of cores: 2
- Cable geometry: Round
- Suspension element: None
- Weight: 44 kg/km
- Weight/100 m: 4 kg
- Low temperature resistant according to EN 60811-504+505+506: No
- Flame retardant according to IEC 60332-1-2: Yes
- Reaction-to-fire according to EN 13501-6: Flaming droplets/particles: None
- Screen over stranding element: None
- Reaction-to-fire according to EN 13501-6: Smoke production: None
- Material outer sheath: Polyvinyl chloride (PVC)
- Screen over stranding: None
- Oil resistant according to EN IEC 60811-404: No
- REACH Date: 2021-06-14
- REACH Information obligation: No
