Telemecanique
Limit switch XCMH
LS Pla Rol lever NC+NO Snap 1m
Article number: Suppl. article no:
3802592
XCMH2110L1
to see price and stock
Limit switch XCMH
- Article number: 3802592
- Suppl. article no: XCMH2110L1
- Ean no: 3389119651257
- Material class QP0400
Technical data
- Type: XCMH2110L1
- Number of contacts as normally open contact: 1
- Number of safety auxiliary contacts: 0
- Number of contacts as change-over contact: 0
- Number of contacts as normally closed contact: 1
- Output electronic: Yes
- Suitable for safety functions: No
- With status indication: No
- Rated operation current Ie at AC-15, 230 V: 0.75 A
- Ambient temperature during operating: -25-70 °C
- Width sensor: 30 mm
- Height of sensor: 60 mm
- Length of sensor: 16 mm
- Forced opening: No
- Rated operation current Ie at DC-13, 230 V: 0.1 A
- Switching function latching: No
- REACH contains candidate substances: Decamethylcyclopentasiloxane (D5) | Dodecamethylcyclohexasiloxane (D6) | Octamethylcyclotetrasiloxane (D4)
- REACH Date: 2024-04-22
- REACH Information obligation: Yes
