Telemecanique
Limit switch XCMH
LS Spring rod NC+NO Snap 2m
Article number: Suppl. article no:
3802568
XCMH2102L1
to see price and stock
Limit switch XCMH
- Article number: 3802568
- Suppl. article no: XCMH2102L1
- Ean no: 3389119650977
- Material class QP0400
- This is an alternative to item 3802141
Technical data
- Type: XCMH2102L1
- Number of contacts as normally open contact (NO): 1
- Number of safety auxiliary contacts: 0
- Number of contacts as change-over contact (CO): 0
- Number of contacts as normally closed contact (NC): 1
- Output electronic: Yes
- Suitable for safety functions: No
- With status indication: No
- Rated operation current Ie at AC-15, 230 V: 0.75 A
- Rated operation current Ie at DC-13, 230 V: 0.1 A
- Ambient temperature during operating: -25-70 °C
- Sensor width: 30 mm
- Height of sensor: 70.4 mm
- Sensor length: 16 mm
- Forced opening: No
- Switching function latching: No
- REACH Date: 2024-04-22
- REACH contains candidate substances: Decamethylcyclopentasiloxane (D5) | Dodecamethylcyclohexasiloxane (D6) | Octamethylcyclotetrasiloxane (D4)
- REACH Information obligation: Yes
