Systemair
Roof Bushing TG, Systemair
ROOF SOCKET TG400-800 SYSTEMAIR
Article number: Suppl. article no:
6510801
1718
to see price and stock
The roof bushing is easy to adjust to the roof angle with the help of the brackets, and it also acts as a muffler. Made of galvanized steel sheet and insulated with 50 mm mineral wool board and perforated inner sheet. The roof pass-through is equipped with plastic pipes and cable entry for electric cable pulling
- Article number: 6510801
- Suppl. article no: 1718
- Material class PNL15B
Technical data
- Width: 393 mm
- Length: 393 mm
- Height: 800 mm
- Insulation thickness: 50 mm
- Outer dimensions: 393 mm
- Opening dimension: 283 mm
- Material: Galvanised steel
- Weight: 24.2 kg
