LK
Ball Valve TA 400, with Blue Handle
BALL VALVE H.LEVER M-THREAD 26 LK SYSTEMS
Article number: Suppl. article no:
4810025
4810025
to see price and stock
Ball valve in high-neck zinc-resistant brass suitable for strains with insulation. Connected with metallic seal and external M-thread on LK PressPex Valve Coupling AX16 - A75. All dimensions have yellow clutch housing and white handle prepared with holes for tag.
- Article number: 4810025
- Suppl. article no: 4810025
- Ean no: 7331590054962
- Material class PAM12B
Technical data
- Packagin Size: 1 ST/32 ST
- Nominal diameter connection 1: DN 15
- Nominal diameter connection 2: DN 15
- Article pressure rating: PN 16
- Connection 1: External thread metric
- Connection 2: External thread metric
- Housing material: Brass
- Fire-safe: No
- FM quality mark: No
- Grease-free: Yes
- Full bore: Yes
- Housing construction: 2-part
- LPCB quality mark: No
- Material ball: Stainless steel
- Material ball seal: Polytetrafluoroethylene (PTFE)
- Material primary spindle seal: Fluorelastomer rubber (FPM/FKM)
- Material secondary spindle seal: Fluorelastomer rubber (FPM/FKM)
- Material quality: Dezincification resistant brass (DZR)
- Max. pressure difference at 20 °C: 30 bar
- With coupling connection 1: No
- With coupling connection 2: No
- Medically clean: No
- Model: Straight
- Material spindle: Brass
- Sealing: Metal-sealing
- Operation: Lever handle
- Handle height: 88 mm
- Handgrip length: 100 mm
- With drain valve: No
- With drain possibility (connection): No
- REACH Date: 2025-06-25
- REACH contains candidate substances: Bly
- Design: M26x1,5
- REACH Information obligation: Yes
- ULC quality mark: No
- UL quality mark: No
