Ceiling shower with mixer and shower set Optima Style, Oras - ORAS OPTIMA STYLE SHOWER SYSTEM, 40C/C, CHROME
Outlet
https://www.youtube.com/watch?v=/external-assets/JPEGlarge800_800/35/71/ProductImage70903571.jpg
https://www.youtube.com/watch?v=/external-assets/JPEGlarge800_800/35/72/ProductImage70903572.jpg
Oras

Ceiling shower with mixer and shower set Optima Style, Oras

ORAS OPTIMA STYLE SHOWER SYSTEM, 40C/C, CHROME
Article number:
8283303
Suppl. article no:
7157N





 to see price and stock
Third party verified Environmental product declaration
Ceiling shower set with thermostatic mixer for shower. User-friendly knob with temperature limitation button 38°, control for Eco flow via push button. The mixer is equipped with non-return valves and dirt filter. Hand shower with eco flow and 3 jet types for a comfortable shower experience. Ceiling shower and hand shower are easy to clean thanks to its anti-limescale nozzles.
The mixer has a magnetic shelf included for attachment to the mixer body which provides a deeper shelf surface.
7.2/13.2L/min @ 3 bar - Eco/shower flows.
  • Article number:
    8283303
  • Suppl. article no:
    7157N
  • Ean no:
    6414150099601
  • Material class
    PCM43A
  • This is an alternative to item
    8343755
Technical data
  • Basic colour: Chrome
  • Centre distance: 40 mm
  • With shower set: Yes
  • With fixed head shower: Yes
  • With diverter unit: Yes
  • With temperature limit: Yes
  • Type of temperature control: Thermostatic
  • Connection supply: External thread
  • Connection size supply: 1/2 inch (15)
  • Material tap: Brass
  • Temperature blocking (38 °C): Yes
  • Surface treatment: Polished
  • Nominal diameter outlet: 1/2 inch (15)
  • Outlet location: Upwards
  • Type of grip: Two-grip
  • Backflow safeguard according to EN 1717: EB
  • Cool housing: Yes
  • Surface protection: Chromium-plated
  • Sound class according to EN ISO 3822: Group I, <= 20 dB(A)
  • KIWA certified: Yes
  • Max. supply temperature: 70 °C
  • With override stop for flow limitation: Yes
  • With rosette: Yes
  • Model: Mechanical
  • Type approval according to BBR/EKS: Yes
  • With pre-filter: Yes
  • GWP-tot (A1-A3): 29,8267 kgCO2e/ST
  • Design: Chrome
