Shower combination Nova/Apollo Eco Energy Class A, Oras
ORAS NOVA SHOWER COMBINATION ECO 160C/C NOVA/APOLLO 7422G
Article number: Suppl. article no:
8283207
7422G
to see price and stock
Oras Nova thermostatic mixer in combination with Oras Apollo Eco. Oras Nova thermostatic mixer compensates for temperature and pressure loss and is equipped with a child-proof temperature control and ceramic shut-off. Oras Apollo Eco is a complete shower set with shower rod, sliding part and soap cup. Oras Apollo has an ergonomic designed hand shower that provides a comfortable shower while saving water and energy Flow up to <9 l/m.
Energy class A according to SS 820001. The product is assessed by Byggvarubedomningen. Manufactured in 4MS approved brass alloy.
Energy class A according to SS 820001. The product is assessed by Byggvarubedomningen. Manufactured in 4MS approved brass alloy.
- Article number: 8283207
- Suppl. article no: 7422G
- Ean no: 6414150100093
- Material class PCL13A
Technical data
- Packagin Size: 1 PCS/4 PCS/48 PCS
- Volume supply class: Z
- With diverter unit: No
- With override stop for flow limitation: Yes
- Centre distance: 160 mm
- Basic colour: Chrome
- Surface treatment: Polished
- With shower set: Yes
- With fixed head shower: No
- Accent colour: Chrome
- With temperature limit: Yes
- Type of temperature control: Thermostatic
- Connection supply: External thread
- Mounting method: Wall
- Connection size supply: M26 x 1.5
- Material tap: Brass
- Temperature blocking (38 °C): Yes
- Nominal diameter outlet: 1/2 inch (15)
- Outlet location: Downwards
- Type of grip: Two-grip
- Backflow safeguard according to EN 1717: EB
- Cool housing: Yes
- Surface protection: Chromium-plated
- Sound class according to EN ISO 3822: Group I, <= 20 dB(A)
- With spout: Yes
- Max. tap capacity (at 300 kPa): 8 l/min
- KIWA certified: Yes
- Shower hose length: 1500 mm
- Length of sliding rod: 650 mm
- Automatic cycle flushing: No
- Max. supply temperature: 75 °C
- With rosette: Yes
- With building management system connection: No
- Model: Mechanical
- Self-closing: No
- Flushing time adjustable: No
- Type approval according to BBR/EKS: Yes
- With pre-filter: Yes
- Number of spray types hand shower: 1
- Anti chalk system: Yes
- Width hand shower head: 70 mm
- Diameter hand shower head: 70 mm
- Shape shower head: Round
- In height-adjustable mounting points: No
- Material handle: Plastic
- With fixed hand shower holder: No
- With integrated shelf: Yes
- Volume supply class hand shower: Z
- REACH Date: 2026-04-13
- REACH contains candidate substances: Bly
- GWP-tot (A1-A3): 14,3865 kgCO2e/ST
- REACH Information obligation: Yes
