Oras
Shower package 150 c/c Nova/Apollo, Oras
ORAS NOVA SHOWER COMBINATION 150C/C NOVA/APOLLO, 7425
Article number: Suppl. article no:
8282822
7425
to see price and stock
Oras Nova thermostat mixer 150 c/c in combination with Oras Apollo 520. Oras Nova thermostat mixer compensates for temperature and pressure loss and is equipped with a child-safe temperature control and ceramic shut-off. Oras Apollo is a complete shower set with shower rod, sliding part and soap dish. Oras Apollo has an ergonomically designed hand shower that gives a comfortable shower.
- Article number: 8282822
- Suppl. article no: 7425
- Ean no: 6414150079023
- Replaces art.nbr: 8343774 8343774V
- Material class PCL130
Technical data
- Packagin Size: 1 ST/4 ST/48 ST
- Design: Shower set with mixer
- With diverter unit: No
- With override stop for flow limitation: Yes
- Centre distance: 150 mm
- Basic colour: Chrome
- With shower set: Yes
- With fixed head shower: No
- Type of temperature control: Thermostatic
- Connection supply: Internal thread
- Connection size supply: 3/4 inch (20)
- Material tap: Brass
- Temperature blocking (38 °C): Yes
- Nominal diameter outlet: 1/2 inch (15)
- Outlet location: Downwards
- Type of grip: Two-grip
- Backflow safeguard according to EN 1717: EB
- Cool housing: Yes
- Locking mechanism: Top section, ceramic
- Surface protection: Chromium-plated
- With spout: Yes
- Type approval according to BBR/EKS: Yes
- REACH Date: 2022-10-13
- REACH contains candidate substances: Bly
- GWP-tot (A1-A3): 13,9526 kgCO2e/ST
- REACH Information obligation: Yes
