Hide-a-lite
Converter Micro MD FDIM, Hide-a-lite
DRIVER MICRO MD FDIM 350MA
Article number: Suppl. article no:
7980932
7980932
to see price and stock
Phase-dimmable converter for constant current 350mA and 700mA, light source can be controlled with standard rotary/push dimmers, for front and rear control. For a list of recommended dimmers, see: www.hidealite.se. Slim form for mounting in the device box with additional space, or together with the Spot Guard Gles fixture (74 667 02).
- Article number: 7980932
- Suppl. article no: 7980932
- Ean no: 7392971127507
- Material class QQ382A
Technical data
- Packagin Size: 1 ST/20 ST
- Output current: 350 mA
- Output voltage: 12-28 V
- Output power: 4.2-10 W
- Degree of protection (IP): IP20
- Suitable for constant voltage: FALSE
- Suitable for constant current: TRUE
- Suitable for DC-voltage (primary side): FALSE
- Suitable for outdoor use: FALSE
- Height: 21 mm
- Length: 102
- Width: 37 mm
- Housing: Plastic housing
- Model: Dynamic
- Protection class according to IEC 61140: II
- Dimmable: TRUE
- Dimming DALI: FALSE
- Dimming 0-10 V: FALSE
- Dimming 1-10 V: FALSE
- Dimming DMX: FALSE
- Dimming DSI: FALSE
- Dimming LineSwitch: FALSE
- Dimming RF: FALSE
- Dimming Zigbee: FALSE
- Dimming potentiometer (integrated): FALSE
- Dimming programmable: FALSE
- Dimming manufacturer's proprietary system: FALSE
- Dimming Touch and Dim: FALSE
- Dimming with push-button: FALSE
- Dimming Sine Wave Reduction: FALSE
- Dimming mains voltage modulation: FALSE
- Dimming phase cut-off (trailing edge): TRUE
- Dimming phase cut-on (leading edge): TRUE
- REACH Date: 2022-06-01
- REACH Information obligation: No
- Dimming GPRS: FALSE
