Designlight
Croc street light
Street Light Croc S-19A50 50W
Article number: Suppl. article no:
7728382
S-19A50
to see price and stock
Stolparmatur Croc, 150x55° asymmetrisk, 4000K, grå pulverlack, IP66. Armaturen levereras med jordad kabel för anslutning. Croc stolparmatur är en enkel och effektiv lampa som passar bra för montage på stolpe Ø 40-60 mm. Vinklingsbart fäste ±15°. Lämpliga användningsområden är: gång- och cykelvägar, motionsslingor, gator, torg eller bostadsområden. Denna produkt är framtagen med fokus på enkelhelhet och prestanda. Med tex. självrengörande ytbehandling och utbytbara komponenter får du en driftsäker produkt som kräver minimalt med underhåll. Lampans smarta fäste går att justera för att passa både horisontell och vertikal montering.
- Article number: 7728382
- Suppl. article no: S-19A50
- Ean no: 7340132803807
- Material class QU0780
Technical data
- Energy label: E
- Max. system power: 50 W
- Rated luminous flux according to IEC 62722-2- 1: 6900 lm
- Colour temperature: 4000 K
- Colour rendering index CRI: 70-79
- Housing colour: Grey
- Lamp type: LED exchangeable
- Cable length: 8 m
- Degree of protection (IP): IP66
- Dimmable: No
- Dimming DALI: No
- Protection class according to IEC 61140: I
- Impact strength: IK08
- Housing material: Aluminium
- Type of control gear: LED operating device current-controlled
- With control gear: Yes
- Adjustable optics: No
- Lamp holder: None
- With light source: Yes
- Mounting method: Post top/side entry
- Nominal voltage: 100-277 V
- Suitable for spigot size: 40-60 mm
- Number of poles: 3
- Dimming phase cut-off (trailing edge): No
- Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24: Yes
- Width: 211 mm
- Dimming with push-button: No
- Dimming Sine Wave Reduction: No
- Dimming mains voltage modulation: No
- Dimming 0-10 V: No
- Dimming 1-10 V: No
- Dimming DMX: No
- Dimming DSI: No
- Dimming LineSwitch: No
- Dimming RF: No
- Dimming Zigbee: No
- Dimming potentiometer (integrated): No
- Dimming programmable: No
- Dimming manufacturer's proprietary system: No
- Power factor: 0.95
- Remote control: None
- Dimming phase cut-on (leading edge): No
- Height/depth: 114 mm
- Constant light output (CLO): No
- Conductor cross section: 1 mm²
- Colour of light: White
- Light distributor: Focal lens
- Luminaire efficacy: 130 lm/W
- Length: 329 mm
- With connection cable: Yes
- With light regulation program control: No
- With radio control: No
- Rated ambient temperature according to IEC 62722-2-1: -20-50 °C
- Voltage type: AC
- Dimming Touch and Dim: No
- Type of wiring: Ending
- Surface protection: Powder coating
- Colour consistency (McAdam ellipse): SDCM3
- Exchangeable control gear: Yes
- Connection type: Other
- REACH Date: 2021-12-21
- REACH Information obligation: No
