Omron
Auxiliary relay and miniature relay type MY
Relay,14-pin,4PDT, 6 A, 24DC
Article number: Suppl. article no:
4002009
MY4IN-D1-GS-R DC24
to see price and stock
Miniature relays with 2-and 4 switching contacts for plug-in in the 8 or 14-pole socket. All relays have mechanical indication of contact status, lamp indication for coil status and lockable test button with guard. Relay with 4 switching contacts has gold-plated silver contacts for low Intermediate resistance as default. Suitable as both signal transmission relay and as a working current relay.
- Article number: 4002009
- Suppl. article no: MY4IN-D1-GS-R DC24
- Ean no: 4550431106254
- Material class QP380B
- This is an alternative to item 4014353
Technical data
- Packagin Size: 1 PCS/10 PCS
- Type: MY4IN-D1-GS-R DC24
- Rated control supply voltage DC: 19.2-26.4 V
- Nominal current: 6 A
- Number of contacts as change-over contact: 4
- Number of contacts as normally closed contact: 0
- Type of switch contact: Single contact
- Type of electric connection: Plug-in connection
- With LED indication: Yes
- Degree of protection (IP): Other
- With detachable clamps: No
- Complete with socket: No
- Height: 28 mm
- Width: 21.5 mm
- Depth: 36 mm
- With forced-guided contacts: No
- Drive, switching attitude: Mono stable
- Drive, polarization: Polarized
- Voltage type for actuating: DC
- Material contact: Other
- Voltage type (operating voltage): DC
- REACH Date: 2024-11-20
- REACH Information obligation: No
