Overvoltage relay LR2K
RELAY 1,2-1,8A LR2K0307
Article number: Suppl. article no:
3236513
LR2K0307
to see price and stock
For direct mounting on mini-contactor series K Convertible manual (H) or automatic (A) recovery. Test function. Closing and breaking signal connector and indication for triggered relay.
- Article number: 3236513
- Suppl. article no: LR2K0307
- Ean no: 3389110230437
- Material class QO360B
Technical data
- Packagin Size: 1 ST/41 ST
- Type: LR2 K0307
- Adjustable current range: 1.2-1.8 A
- Number of auxiliary contacts as normally open contact: 1
- Number of auxiliary contacts as normally closed contact: 1
- Number of auxiliary contacts as change-over contact: 0
- Release class: CLASS 10 A
- Mounting method: Direct attachment
- Type of electrical connection of main circuit: Screw connection
- Max. rated operation voltage Ue: 690 V
- Reset function automatic: Yes
- Reset function push-button: Yes
- Reset function input: No
- REACH Date: 2025-07-18
- REACH Information obligation: No
