Schneider Electric
Mini contactor LC1K AC operated
Contactor AC1 20A 220...230V LC1K09008M7
Article number: Suppl. article no:
3230639
LC1K09008M7
to see price and stock
3 or 4 main poles
- Article number: 3230639
- Suppl. article no: LC1K09008M7
- Ean no: 3389110488876
- Material class QO360B
Technical data
- Packagin Size: 1 ST/50 ST/400 ST
- Type: LC1K09008M7
- Rated operation power at AC-3, 400 V: 0 kW
- Rated operation current Ie at AC-1, 400 V: 20 A
- Rated operation current Ie at AC-3, 400 V: 0 A
- Rated control supply voltage AC 50 Hz: 220-230 V
- Rated control supply voltage DC: 0 V
- Number of normally open contacts as main contact: 2
- Number of normally closed contacts as main contact: 2
- Voltage type for actuating: AC
- Number of auxiliary contacts as normally open contact: 0
- Number of auxiliary contacts as normally closed contact: 0
- Type of electrical connection of main circuit: Screw connection
- Suitable for distribution board: No
- Rated operation current Ie at AC-4, 400 V: 0 A
- Rated operation power at AC-4, 400 V: 0 kW
- Width: 45 mm
- Depth: 57 mm
- Operating voltage AC 50 Hz: 440 V
- Operating voltage AC 60 Hz: 440 V
- Height: 58 mm
- Rated control supply voltage AC 60 Hz: 220-230 V
- REACH Date: 2025-07-18
- REACH Information obligation: No
