Schneider Electric
Contactor TeSys D Green
CONTACTOR-3P-AC3-<=440V 25A - LC1D25KUE
Article number: Suppl. article no:
3230032
LC1D25KUE
to see price and stock
TeSys D Green - a green range of contactors.
The products are equipped with an innovative electronic coil that uses up to 80 percent less energy and generates up to 50 percent less heat inside electrical cabinets compared to electromechanical contactors.
TeSys D Green helps large process and manufacturing industries to reduce energy costs and achieve their sustainability goals.
• Innovative electronic coil reduces energy costs
• Robust design increases process reliability
• Connection directly via PLC control
• Flexibility to meet requirements and enable replacement of standard contactors
• Easy to install and use
The products are equipped with an innovative electronic coil that uses up to 80 percent less energy and generates up to 50 percent less heat inside electrical cabinets compared to electromechanical contactors.
TeSys D Green helps large process and manufacturing industries to reduce energy costs and achieve their sustainability goals.
• Innovative electronic coil reduces energy costs
• Robust design increases process reliability
• Connection directly via PLC control
• Flexibility to meet requirements and enable replacement of standard contactors
• Easy to install and use
- Article number: 3230032
- Suppl. article no: LC1D25KUE
- Ean no: 3606480987748
- Material class QO360B
Technical data
- Packagin Size: 1 ST/15 ST
- Number of normally open contacts as main contact: 3
- Number of normally closed contacts as main contact: 0
- Number of auxiliary contacts as normally open contact: 1
- Number of auxiliary contacts as normally closed contact: 1
- Rated operation power at AC-3, 400 V: 11 kW
- Rated operation current Ie at AC-1, 400 V: 40 A
- Rated operation current Ie at AC-3, 400 V: 25 A
- Rated control supply voltage AC 50 Hz: 100-250 V
- Rated control supply voltage DC: 100-250 V
- Voltage type for actuating: AC/DC
- Type of electrical connection of main circuit: Screw connection
- Suitable for distribution board: No
- Width: 45 mm
- Depth: 92 mm
- Operating voltage AC 50 Hz: 440 V
- Operating voltage AC 60 Hz: 440 V
- Height: 85 mm
- Rated control supply voltage AC 60 Hz: 100-250 V
- REACH Date: 2025-07-18
- REACH contains candidate substances: Bly | Boroxid, Diboron trioxide
- REACH Information obligation: Yes
