Schneider Electric
Auxiliary relay CA2 AC operated
ELECTROMAGNETIC RELAY CA2KN40M7
Article number: Suppl. article no:
3230234
CA2KN40M7
to see price and stock
AC operated
- Article number: 3230234
- Suppl. article no: CA2KN40M7
- Ean no: 3389110500332
- Material class QO360B
Technical data
- Packagin Size: 1 ST/10 ST/50 ST
- Type: CA2-KN40M7
- Rated control supply voltage AC 50 Hz: 220-230 V
- Voltage type for actuating: AC
- Rated operation current Ie, 400 V: 10 A
- Connection type auxiliary circuit: Screw connection
- Number of auxiliary contacts as normally open contact: 4
- Number of auxiliary contacts as normally closed contact: 0
- Number of auxiliary contacts as normally closed contact, delayed switching: 0
- Number of auxiliary contacts as normally open contact, leading: 0
- Number of auxiliary contacts as change-over contact: 0
- Rated control supply voltage AC 60 Hz: 220-230 V
- Width: 45 mm
- Depth: 84 mm
- Height: 77 mm
- Interface: No
- Suitable for manual operation: No
- With LED indication: No
- Mounting method: DIN-rail/screw
- Operating voltage AC 50 Hz: 690 V
- Operating voltage AC 60 Hz: 690 V
- Rated operation current: 10 A
- Rated switch current: 0.005 A
- Voltage type (operating voltage): AC
- REACH Date: 2025-07-18
- REACH Information obligation: No
