Pipelife
Pragma bend 45°
200x30° BEND PRAGMA EN13476 PBB.5216
Article number: Suppl. article no:
2340165
70000374
to see price and stock
Pipe parts for Pragma lightweight pipes in double-wall construction. Manufactured according to Nordic quality requirements INSTA-CERT, Nordic Poly Mark. Supplied with sealing ring in EN681-1 quality.
- Article number: 2340165
- Suppl. article no: 70000374
- Ean no: 9010459143006
- Material class PMG110
Technical data
- Packagin Size: 1 PCS/5 PCS/40 PCS
- Outer pipe diameter connection 1: 200 mm
- Outer pipe diameter connection 2: 200 mm
- Bend angle: 30 °
- Eccentric: No
- Reducing: No
- Ring stiffness class: SN8
- Connection 1: Slide end
- Connection 2: Slide sleeve
- Material connection 1: Polypropylene (PP)
- Material connection 2: Polypropylene (PP)
- Material quality connection 1: PP-C
- Material quality connection 2: PP-C
- With sealing rings/gaskets: Yes
- Shape: Bend
- Model: 1-part
- Capped: No
- With de-aerator: No
- With drain valve: No
- With buffer stud: Yes
- Surface treatment connection 1: Untreated
- Surface treatment connection 2: Untreated
- Surface protection connection 1: Untreated
- Surface protection connection 2: Untreated
- System specific: Yes
- Norm: EN13476
- Design: Muff and tip end
- REACH Date: 2021-06-07
- GWP-tot (A1-A3): 1,6585 kgCO2e/ST
- Ring stiffness: SN8
- Material: PP
- Colour: Red-brown
- REACH Information obligation: No
