Control valve ESBE VLE132 3-way. Threaded
CONTROL VALVE VLE132 3-WAY ESBE PN16 G1 DN15 KVS 4.0
Article number: Suppl. article no:
5362188
21251500
to see price and stock
- Article number: 5362188
- Suppl. article no: 21251500
- Ean no: 7330193025805
- Replaces art.nbr: 4551445V
- Material class PEF40B
Technical data
- Connections: External thread
- Article compression class: PN 16
- Kvs value: 4
- Leakage loss of Kvs value: 0.02 %
- Material quality: Bronze (Rg 5)
- Nominal diameter: DN 15
- Housing material: Bronze
- Stroke length: 20 mm
- Max. pressure difference in opened position: 6 bar
- Surface protection: Untreated
- With coupling connection 3: No
- With coupling connection 1: No
- With coupling connection 2: No
- Characteristic curve: Equal percentage
- Length of connection 1: 50 mm
- Length of connection 2: 50 mm
- Length of connection 3: 50 mm
- Outer pipe diameter all connections: 25 mm
- Kvs value for bypass: 4
- Medium temperature (continuous): -20-120 °C
- REACH Date: 2021-01-19
- REACH contains candidate substances: Bly
- REACH Information obligation: Yes
