Siemens
Control valve 3-way VXG44, Siemens
25 CONTR VALVE VXG44.25-10 3-WAY, KVS 10 PN16 G
Article number: Suppl. article no:
5353710
BPZ:VXG44.25-10
to see price and stock
3-way valve without actuator
- Article number: 5353710
- Suppl. article no: BPZ:VXG44.25-10
- Ean no: 7612914011534
- Material class PEF20B
Technical data
- Connections: External thread
- Article compression class: PN 16
- Kvs value: 10
- Leakage loss of Kvs value: 0.02 %
- Material quality: Bronze (Rg 5)
- Nominal diameter: DN 25
- Housing material: Bronze
- Stroke length: 5.5 mm
- Max. pressure difference in opened position: 4 bar
- Surface protection: Untreated
- With coupling connection 3: Yes
- With coupling connection 1: Yes
- With coupling connection 2: Yes
- Characteristic curve: Linear
- Length of connection 1: 52.5 mm
- Length of connection 2: 52.5 mm
- Length of connection 3: 62.6 mm
- Outer pipe diameter all connections: 25 mm
- Kvs value for bypass: 10
- Flange compression class: PN 16
- Leakage loss of Kvs value for bypass: 0.02 %
- Control ratio (Svo): 100 %
- Installation method, distributive: No
- Working length connection 1: 52.5 mm
- Working length connection 2: 52.5 mm
- Working length connection 3: 62.6 mm
- Characteristic curve for bypass: Linear
- Axle height: 71 mm
- With T-piece for 4-way connection: No
- Type: VXG44.25-10
