Grooved acid-proof stainless steel 316L concentric cone

GROOVED SS REDUCER DN65X50 316L-76.1MMX60.3MM

Article number:

1676004

Suppl. article no:

SRG 76.1X3.05-60.3X2

‌
‌
‌

‌
‌

to see price and stock

Nordic Flow concentric reducer in acid-resistant stainless steel (316L) is intended for dimensional changes in grooved pipe systems. The product is grooved according to the OGS standard (Original Groove System)
Applications
Sprinkler systems
HVAC installations
Heating
Cooling
Rainwater systems
Compressed air systems
Approvals
FM-approved for dimensions DN50–DN200
Ahlsell's grooved acid-resistant stainless steel system is type approved by RISE (Certificate number: C900956)
Assessed by Sundahus and Byggvarubedömningen.

Article number:
1676004
Copy to clipboard
Suppl. article no:
SRG 76.1X3.05-60.3X2
Copy to clipboard
Ean no:
7333123092700
Copy to clipboard
Material class
PJG390
Copy to clipboard

Technical data

Packagin Size: 1 ST/15 ST/150 ST/600 ST
Nominal diameter connection 1: DN 65
Nominal diameter connection 2: DN 50
Outer pipe diameter connection 1: 76.1 mm
Outer pipe diameter connection 2: 60.3 mm
Max. operating pressure at 20 °C: 20.7 bar
Weight / item: 0.42 kg
Connection 1: Groove
Connection 2: Groove
Material connection 1: Stainless steel
Material connection 2: Stainless steel
Material quality connection 1: Stainless steel 316 L (1.4404)
Material quality connection 2: Stainless steel 316 L (1.4404)
Bend angle: 0 °
Shape: Straight
Reducing: Yes
Length: 76 mm
Medium temperature (continuous): 0-100 °C
DIN-CERTCO certificate: No
High tensile strength: No
With drain valve: No
With buffer stud: No
With de-aerator: No
System specific: No
Eccentric: No
With connection indicator: No
With thermal insulation: No
REACH Date: 2026-02-04
REACH Information obligation: No
