Grooved elbow 90º, Stainless Steel, a-collection

GROOVED SS 90º ELBOW DN100 316L-114.3 MM

Article number:

1678006

Suppl. article no:

90G 114.3X3.05

‌
‌
‌

‌
‌

to see price and stock

Nordic Flow 90° grooved elbow in acid-resistant stainless steel (316L) is intended for use in OGS (Original Groove System) grooved pipe systems.
Areas of application
Sprinkler systems
HVAC installations
Heating
Cooling
Rainwater systems
Compressed air systems
Approvals
FM-approved for dimensions DN50–DN200.
Ahlsell's grooved acid-resistant stainless steel system is type approved by RISE (Certificate number: C900956).
Assessed by SundaHus and Byggvarubedömningen.

Article number:
1678006
Copy to clipboard
Suppl. article no:
90G 114.3X3.05
Copy to clipboard
Ean no:
7333123092267
Copy to clipboard
Material class
PJG360
Copy to clipboard

Technical data

Packagin Size: 1 ST/4 ST/40 ST/160 ST
Nominal diameter connection 1: DN 100
Nominal diameter connection 2: DN 100
Outer pipe diameter connection 1: 114.3 mm
Outer pipe diameter connection 2: 114.3 mm
Max. operating pressure at 20 °C: 20.7 bar
Weight / item: 2.04 kg
Connection 1: Groove
Connection 2: Groove
Material connection 1: Stainless steel
Material connection 2: Stainless steel
Material quality connection 1: Stainless steel 316 L (1.4404)
Material quality connection 2: Stainless steel 316 L (1.4404)
Bend angle: 90 °
Shape: Bend
Reducing: No
Medium temperature (continuous): 0-100 °C
DIN-CERTCO certificate: No
High tensile strength: No
With drain valve: No
With buffer stud: No
With de-aerator: No
Capped: No
System specific: No
Eccentric: No
With connection indicator: No
With thermal insulation: No
REACH Date: 2026-02-04
REACH Information obligation: No
