Grooved acid-proof lid with centric thread

GROOVED CEN.SS CAP DN50XG32 316 L- 60.3MM X 42.4 BSPT

Article number:

1480030

Suppl. article no:

MBF 60.3-32

‌
‌
‌

‌
‌

to see price and stock

Nordic Flow grooved cap with internal centric BSPT thread is designed to enable a transition between grooved and threaded pipe systems. The product is grooved according to OGS (Original Groove System).
Areas of application
Sprinkler systems
HVAC installations
Heating
Cooling
Rainwater systems
Compressed air systems
<Approvals
Ahlsell's grooved acid-resistant stainless steel system is type approved by RISE (Certificate number: C900956).
Assessed by Sundahus and Byggvarubedömningen.
The dimensions DN250 and DN300 have a different design. See the data sheet for more information.

Article number:
1480030
Copy to clipboard
Suppl. article no:
MBF 60.3-32
Copy to clipboard
Ean no:
7333123838544
Copy to clipboard
Material class
PJG420
Copy to clipboard

Technical data

Packagin Size: 1 PCS/1 PCS/10 PCS/40 PCS
Nominal diameter connection 1: DN 50
Nominal diameter connection 2: DN 32
Outer pipe diameter connection 1: 60.3 mm
Outer pipe diameter connection 2: 42.4 mm
Max. operating pressure at 20 °C: 16 bar
Weight / item: 0.26 kg
Connection 1: Groove
Connection 2: Internal thread conical BSPT-Rc (ISO 7-1 / EN 10226-1)
Material connection 1: Stainless steel
Material connection 2: Stainless steel
Material quality connection 1: Stainless steel 316 L (1.4404)
Material quality connection 2: Stainless steel 316 L (1.4404)
Shape: Straight
Reducing: Yes
Length: 23.5 mm
REACH Date: 2026-02-04
REACH Information obligation: No
